Neonox Titanium Gr 5 Flanges
Titanium Gr 5 Flanges – High Strength & Lightweight Performance
Titanium Gr 5 flanges are widely recognized for their exceptional strength, lightweight nature, and superior corrosion resistance. At Neonox, these flanges are manufactured using high-grade Titanium Grade 5 alloy, offering excellent mechanical properties and making them ideal for demanding industrial applications, including aerospace, marine, and chemical industries.
Neonox provides Titanium Gr 5 flanges in various types such as raised face, lap joint, slip-on, socket weld, and blind flanges. Each type is designed to meet specific operational needs—raised face flanges are suitable for high-pressure systems, while socket weld flanges are ideal for low to medium pressure applications, ensuring reliable and efficient performance across diverse environments.
Titanium Gr 5 RTJ Flanges, Titanium Gr 5 Blind Flanges, Titanium Alloy Gr 5 Socket Weld Flanges, Titanium Gr 5 Threaded Flanges, Titanium Gr 5 Lap Joint Flanges Supplier in India – Neonox
Titanium Gr 5 flanges are widely used across industries due to their exceptional strength and corrosion resistance. At Neonox, these flanges are commonly applied in chemical processing plants, shipbuilding, oil & gas, offshore platforms, and pulp & paper industries. Their ability to perform efficiently in high-temperature and corrosive environments makes them a reliable choice for demanding industrial applications.
Titanium Gr 5 Flanges Specifications
| Standard | ASTM B564 / ASME SB564 |
|---|---|
| Dimensions | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flange, ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS S44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092 |
| Flange Size Chart | 1/2" (15 NB) to 48" (1200NB), DN10~DN5000 |
| Pressure Rating | Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS |
| Pressure Calculation in DIN | 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64 |
| JIS | 16 K, 5K, 10 K, 20 K, 30 K, 40 K, 63 K |
| Flange Connection / Flange Face Type | Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove, Groove, Flange Pipe. |
| Origin | West Europe / Japan / Indian / USA / Korean |
| Types of Flanges | Threaded / Screwed / Forged / Plate |
| Coating | Yellow Transparent, Zinc Plated, Anti-rust Paint, Oil Black Paint, Cold and Hot Dip Galvanized |
| Test Of Flange | Direct-reading Spectrograph, Ultrasonic flaw detector, Magnetic particle detector, X-ray detector, Hydrostatic testing machine. |
| Production technique Used | Heat treated, Forged and Machined |
| Equipment | Press machine, Bending machine, Pushing Machine, Sand-blasting machine, electric bevelling machine etc. |
| Test Certificates | EN 10204/3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report, etc |
Titanium Gr 5 Nipoflange, Titanium Gr 5 Forged Flanges, Titanium Gr 5 SWRF Flanges, Titanium Gr 5 Forged Flanges Supplier in India – Neonox
Titanium Gr 5 flanges are widely used across various industries for both high-pressure and low-pressure applications. At Neonox, these flanges are ideal for transporting corrosive fluids, manufacturing exhaust systems, and serving as reliable pipe fittings. Their ability to withstand high temperatures and harsh environments ensures long-lasting performance in demanding conditions.
Neonox Titanium Gr 5 flanges offer an exceptional strength-to-weight ratio, making them suitable for applications where both strength and lightweight properties are essential. They are also non-toxic and biocompatible, making them suitable for medical and specialized applications. Their excellent corrosion resistance further enhances durability and extends equipment life.
Designed for versatility and performance, Titanium Gr 5 flanges by Neonox provide a strong, durable, and cost-effective solution for industrial use. Available in various types, they meet diverse operational requirements while ensuring reliability, efficiency, and long-term value.
